Place of Origin: | China |
ชื่อแบรนด์: | JVT |
ได้รับการรับรอง: | ISO9001/SGS/UL/ROHS/Reach |
Model Number: | JVT1124 |
Minimum Order Quantity: | 1000 PCS |
---|---|
ราคา: | Negotiation |
Packaging Details: | PE bag packing +outer carton |
Delivery Time: | 7-10 working days |
Payment Terms: | T/T or Western Union |
Supply Ability: | 300000 per month |
Application: | Signal, Wire-to-Board, Wire-to-Wire | equivalent: | PH series |
---|---|---|---|
Pitch - Mating Interface: | 2.0mm | poles: | 2 - 15 |
Category: | Crimp Housings | Flammability: | 94V-0 |
terminal housing 2 pin, white colour ,pitch 2.0mm equivalent of JST PH series
JVT1124 series is offered in wire-to-board and wire-to-wire options. The system saves about 45% of PCB space compared to typical 2.00mm wire-to-board systems. It is a single row system, available in 2 to 15 circuits, with both surface mount and through-hole headers.
A full range of automatic, semi-automatic and manual tooling is available to support crimp harness assembly using discrete wires.
Specification Standardized:
Insulator Material:PA66
Insulator Flammability: UL94V-0
Terminal Material: Phosphor bronze or brass
Operating temperature: -25 + 85°C
Climatic category (IEC): 55/125/21
Operating Humity range: Annual mean 75%
Insulator color: black, gray, white
Tail style: straight DIP type, SMT type- straight, SMT type- horizontal
Pitch | 1.25mm | 2.00mm | 2.50mm | 2.54mm | 3.96mm | 4.20mm |
Current Rating | 1 Ampere | 2 Ampere | 3 Ampere | 3 Ampere | 7 Ampere | 5-9 Ampere |
Contact Resistance(Max) | 20m ohm | 20m ohm | 20m ohm | 20m ohm | 20m ohm | 20m ohm |
Withstand Voltage for one minute | 500 V AC | 500 V AC | 500 V AC | 500 V AC | 500 V AC | 500 V AC |
Insulator Resistance(Min) | 100 M ohm | 100 M ohm | 100 M ohm | 100 M ohm | 100 M ohm | 100 M ohm |
Application
Our products are widely used in a variety of markets and applications, including:
JVT offer a complete range of board to board and board to wire connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .
All are offered with small moq's ,the majority being stocked items .
Equipment and Service:
10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines
prefessional and patient pre-service & after-service
professsional sales team & engineering team & techinology team
puntual delivery time and complete packaging process
preferable price and best quality
